(Deck Height) - Height of the base to where the glass can be seen. The iron sights you need should be calculated from the base of the optic cut or plate. If you have a deck height of 8mm, that means it will obstruct 8mm of height, plus or minus any recess or protrusion from the slide.
Dimensions - LxWxH, Displayed below in both mm and inches, measured at the base
WOLF0 (10mm)- 46x29x26mm → 1.81 x 1.14 x 1.02 inches
WOLF2 (10mm)- 46x29x26mm → 1.81 x 1.14 x 1.02 inches
CT2 (10mm)- 45x28x26mm → 1.77 x 1.10 x 1.02 inches
CALF V2 (10mm)- 46x30x26mm → 1.81 x 1.18 x 1.02 inches
CALF X1 (10mm)- 46x30x26mm → 1.81 x 1.18 x 1.02 inches
CAT PRO (7.5mm)- 41x28x26mm → 1.61 x 1.10 x 1.02 inches
CAT G-PRO (7.5mm)- 41x28x26mm → 1.61 x 1.10 x 1.02 inches
CAT X PRO (7.5mm)-- 41x28x26mm → 1.61 x 1.10 x 1.02 inches
CAT SRS6 PRO (7.5mm)-- 41x28x26mm → 1.61 x 1.10 x 1.02 inches
CAT0 (9mm)- 41x28x25mm → 1.61 x 1.10 x 0.98 inches
CAT0-G (9mm)- 41x28x25mm → 1.61 x 1.10 x 0.98 inches
WOLF PRO (8.5mm)-- 45x30x27mm → 1.77 x 1.18 x 1.06 inches
WOLF X PRO (8.5mm)- 45x30x27mm → 1.77 x 1.18 x 1.06 inches
WOLF SRS6 PRO (8.5mm)- 45x30x27mm → 1.77 x 1.18 x 1.06 inches
Chameleon SRS8 (9mm)- 51x30x32mm → 2.01 x 1.18 x 1.26 inches
Chameleon G-SRS8 (9mm)- 51x30x32mm → 2.01 x 1.18 x 1.26 inches
WOLF EDG (7.5mm)- 45x29x28mm → 1.77 x 1.14 x 1.10 inches
WOLF G-EDG (7.5mm)- 45x29x28mm → 1.77 x 1.14 x 1.10 inches
CAT EDG (7.5mm)- 41x30x28mm → 1.61 x 1.18 x 1.10 inches
COBRA X PRO (8.5mm)- 46x31x30mm → 1.81 x 1.22 x 1.18 inches
GHOST HDG (8.5mm)- 52x34x35mm → 2.05 x 1.34 x 1.38 inches
BULL X PRO (8.5mm)- 54x42x37mm → 2.13 x 1.65 x 1.46 inches
BULL PRO (8.5mm)- 54x42x37mm → 2.13 x 1.65 x 1.46 inches
SHARK X PRO (7.8mm)- 46x31x30mm → 1.81 x 1.22 x 1.18 inches
